We build steel putty mixers to your required tank size, motor power, and agitator blade configuration. Tell us your material type and batch capacity and we’ll configure the right machine for your production.
The Steel Putty Mixer Machine is an advanced machine used for high-quality mixing under controlled conditions. It is fully made of stainless steel to ensure durability and contamination-free processing. The mixer operates under vacuum, which removes air bubbles from the product and significantly improves the consistency and quality of the final output.
Inside the tank, temperature and pressure are carefully controlled to achieve the desired mixing results for each specific formulation. The machine is equipped with a hydraulic system for lifting, tilting, or handling the mixing vessel smoothly. The motor and mixing blades — also known as agitators — are selected according to the specific material and production requirements. Special stainless steel components are used to handle sensitive or reactive materials safely.
- Full stainless steel construction — durable and contamination-free
- Vacuum operation — removes air bubbles for superior product quality
- Temperature and pressure control inside the mixing tank
- Heating and cooling jacket for precise temperature management
- Hydraulic system for smooth lifting, tilting, and vessel handling
- Motor and agitator blade selection based on material requirements
- Tank size and design customizable by batch capacity
- Suitable for sensitive and reactive materials
- Available in 30 kW, 45 kW, and 75 kW configurations
- Up to 1000 kg vessel working capacity
| Specification | Model 1 | Model 2 | Model 3 |
|---|---|---|---|
| Main Motor Power | 30 kW | 45 kW | 75 kW |
| Main Motor (HP) | 40.2 HP | 60.3 HP | 100.6 HP |
| Vessel Capacity | 250–500 kg | 1000 kg | 1000 kg |
| Disc Rotation | 0–1000 RPM | 0–1000 RPM | 0–1000 RPM |
| Disc Diameter | 300 mm | 325 mm | 400 mm |
| Construction | Full Stainless Steel | Full Stainless Steel | Full Stainless Steel |
| Operation | Vacuum | Vacuum | Vacuum |
| Lifting System | Hydraulic | Hydraulic | Hydraulic |
- Steel putty production
- Wall putty manufacturing
- Tile adhesive production
- Waterproofing compounds
- Cosmetics & personal care
- Food processing (food-grade configurations)
- Pharmaceutical mixing
- Chemical compounds requiring vacuum mixing
- Sensitive and reactive material processing
Tell us your required batch size, motor power, and material type. CEO Muhammad Ahmad will provide a factory-direct price and configure the right agitator and tank setup for your production needs.
