Attrition Machine

Heavy-duty industrial mixer for thick, viscous, and dense materials — manufactured in Lahore, Pakistan. Simple robust construction. No hydraulic system required. Factory-direct pricing.

All Our Machines

Need a Custom Attritor?

We build attritor machines to your required motor power, tank size, and rod or paddle configuration. Tell us your material type and batch size and we’ll configure the right machine for your production.

Attritor Machine — Heavy-Duty Mixer for Viscous Materials

The Attritor Machine is designed for heavy-duty mixing of thick and highly viscous materials. It is commonly used for dense batches where strong mechanical force is required to achieve uniform blending. The machine is equipped with a powerful motor, selected according to the batch size and material consistency — making it suitable for a wide range of demanding industrial applications.

Inside the tank, strong rods or paddles made of heavy-duty metal are installed to handle tough materials. These rods are fixed at one end and rotate to push and fold the material effectively throughout the mixing cycle. Unlike other mixers that rely on hydraulic systems, the Attritor has a simple, robust construction with no hydraulic components — making it easier to maintain and operate over the long term.

How It Works

Step 1: The powerful motor drives the central shaft which rotates the heavy-duty mixing rods or paddles at the required speed.
Step 2: The rotating rods push and fold the dense, viscous material continuously — applying strong mechanical force throughout the vessel.
Step 3: The horizontal tank design allows gravity to assist in the even distribution and handling of thick, heavy mixtures.
Step 4: Additional materials or ingredients can be added from the top of the tank during operation without stopping the machine.
Step 5: Once mixing is complete, the discharge valve at the bottom of the tank allows easy and controlled removal of the finished batch.

Key Features & Advantages

Powerful motor for heavy-duty dense and viscous material mixing
Heavy-duty metal rods or paddles for strong mechanical mixing action
Simple robust construction — no hydraulic system required
Horizontal tank design for better thick-mixture handling
Top loading — add ingredients without stopping the machine
Bottom discharge valve for easy and controlled batch removal
Motor and paddle configuration selected based on material and batch size
Low maintenance — simple design means fewer components to service
Suitable for highly viscous, dense, and abrasive substances

Specifications

Specification	Details
Main Motor Power	15 kW / 20 HP
Dispersing Disc Rotation	75 RPM
Dispersing Disc (g/ns)	200
Tank Orientation	Horizontal
Lifting System	None — simple robust design
Loading	Top loading during operation
Discharge	Bottom discharge valve
Paddle Type	Heavy-duty metal rods or paddles
Configuration	Custom — based on batch size and material

Applications & Industries

Heavy-duty paint formulations
Dense chemical compounds
Construction material mixes
Thick putty and adhesive production
Ceramic pastes
Rubber and polymer compounds
Heavy pigment pastes
Industrial sealants and mastics

Get a Quote for the Attritor Machine

Tell us your required batch size, material type, and motor power. CEO Muhammad Ahmad will provide a factory-direct price and configure the right rod or paddle setup for your production needs.
